NEWTRY Hydraulic Ram Jack 10T Hydraulic Cylinder Low Profile Ram Jack Multi-Section 1 inch Stroke Lifting Cylinder Mini Portable for Machinery, Bridge, Construction

Features

• Technical Specifications---Tonnage: 10T | Stroke 1: 0.5 inch/13MM | Stroke 2: 0.5 inch/13MM | Stroke 3: / | Total stroke: 1 inch/26MM | Oil storage capacity: 22CC | Self height: 2 inches/51MM | Weight: 3.5 lbs/1.6kg | Compression area: 1.75 square inches/11.3cm2 | Inner diameter 1: 1.1 inches/28mm | Inner diameter 2: 1.5 inches/38mm | Inner diameter 3: / | External diameter: 2.6x3.3 inches/66x83mm
• Multi - Section Design for Narrow Spaces---This low-profile hydraulic jack stands at just 2 inches in height, yet it has a stroke of up to 1 inch. Unlike regular jacks, its multi - section design enables it to be used in much narrower and lower spaces. It effectively maximizes the jack's stroke within the body height, allowing you to lift weights to a greater height. This makes it a more convenient and practical choice for various applications.
• Durable Construction for Long-Term Use---This ram jack has a smooth surface with distinct ring marks, which not only ensure smooth lifting but also provide a good grip. The piston is treated with a blackening process, significantly extending its lifespan. This durable construction means you can rely on it for long - term use without frequent replacements.
• Convenient Mounting Options---Featuring two pre-drilled holes, this multi - section jack offers convenient mounting options. Whether you need to install it in a workshop, these holes simplify the mounting process. Just note that after pressure release, the piston needs external gravity to retract.
• Leak - Proof and Dust - Resistant Design---The joints of this hydraulic jack are equipped with a plastic dust - proof cap. It prevent oil leakage and keep dust away from the internal components, maintaining the jack's performance over time. This leak - proof and dust - resistant design ensures that the jack remains in good working condition.
