Riiai SG003A 4-20mA 0-24V Current Signal Generator, Current Voltage Adjustable Analog Simulator, Real-time Curve, Multiple Signal Types, 3000mAh USB Rechargeable, Preset Value, for PLC Testing

Features

• Precise Conversion of Various Signal Types The 4-20ma signal generator is upgraded to support switching various signal modes available under different signal types: mA Current Signal (0 to 24 mA, precision 0.01mA), V Voltage Signal (0 to 24V, 0.01V), XMT Passive Current Signal (0 to 24mA, precision 0.01mA), Hz Pulse Signal (Frequency Output 0 to 9999 Hz, precision 5 digits). The input signal can be converted into an output signal among different physical quantities
• 2.4 Inch TFT Colorful Screen Designed with an adjustable pressing button backlight and a high-definition 240*320 TFT color LCD screen, it makes the signal generator kit for PLC testing easier for users to operate at night and during the day
• Built-in 3000 mAh USB Rechargeable With a 3000 mAh 3.7V built-in USB rechargeable battery embedded inside (charged via a micro 5V USB port), the function generator can be fully charged within 4-6 hours. Its working length of up to 26 hours allows for a longer working period
• Multiple Interfaces to Choose Main interface programmable output. Input waveform interface: switchable input current graph display, input voltage graph display. VCA conversion interface: switchable voltage to active current, voltage to passive current, current to voltage. Automatic interface: automatic mode can be set for single ascent, single drop, and loop. PWM interface: Output PWM signal, voltage, frequency, and duty cycle can be set
• Programmable Output The 4-20 ma signal generator has the output function of auto, continuously changes the size according to the set parameters, and chooses three modes: monotonous rise, monotonous fall, and cycle
