Altera MAX10 FPGA Development Board - MaxProLogic

Features

• Altera 10M04SA FPGA with 4,000 Logic Elements. This FPGA Development Kit requires an external JTAG Programmer. The MAX10 FPGA is a great chip to learn FPGA programming with. The MAX10 includes the configuration flash, 12 bit ADC, 20KByte of SRAM and low voltage regulators on chip.
• The board includes a 50MHz Oscillator to provide high speed control over internal gates of the MAX 10 FPGA. With 4K Logic Elements, the User can create powerful projects. The MaxProLogic is 100% compatible with the Free Quartus Prime Lite software from Altera. Just download the Quartus software from Altera, and the User can create projects, compile the code, simulate the project in a digital simulator, then download to the MAX 10 using an external programmer.
• 8 Analog Input Channels; 12 bit; 1MSamples/Second. 65 Available I/Os at connectors. A full datasheet of the MaxProLogic is available that describes all the hardward connections. Schematic is available to give the User further information about the hardware.
• 8 Green User configurable LEDs, On/Off controller. 1 Power Pushbutton Switch; 1 User Configurable Pushbutton Switch. Source code is available to assist the user in understanding how get up and running with the MaxProLogic board.
• Complete Development Kit with tutorials and source code. Please visit the MaxProLogic product page under the earthpeopletechnology website to access all schematics, user manual, data sheets and project files. The MaxProLogic tutorials will get the beginner up and learning Programmable Logic very quickly.
